Big enough to get the job done, and yet still small enough to care!
Big enough to get the job done, and yet still small enough to care!
Our 47,000 square foot facility is more than enough space to manufacture, cut, weld, or develop your part needs from start to finish.
Our Value
If you are looking for a dedicated company who values quality and the hard working American manufacturer, then look no further. With American Quality Fabrication, you'll get quality parts at fair market value with high precision and detail. We are sure you will feel confident with having us work on your next project. American Owned & Operated, Supporting American Workers and Their Families!
List of Services
-
CuttingList Item 1
- Mazak Optiplex 3015-400 watt laser w/2-60"x120" tables
- Mazak Laser Champ-1500 watt laser w/1-48"x96" table
- Mazak Nexus 6kW Fiber w/2-60"x120" tables
- 12' Cincinnati Sheer
- Hyd-Mack CNC Automatic Saw
- Thermal Arc Plasma Cutter
-
Press Brake FormingList Item 2
- Cincinnati 12'-175 Ton CNC Controls and 5 Axis Back Guage Press Brake
- Cincinnati 11'-135 Ton CNC Controls and 5 Axis Back Guage Press Brake
- Accur-Bend 6'-44 Ton CNC Controls Press Brake
-
Roll FormingList Item 3
- Qty (1)-WDM Pinch Roll
-
NotchingList Item 4
- Bashert 8" Corner Notcher
-
Punching
- Qty (1)-Amada Vipros 255 Turret
-
Welding
- Qty (10)-250 Amp Wire Feed MIG Welder (GMAW)
- Qty (7)-275 Amp TIG Welders (GTAW)
- Qty (1)-300 Amp Push Pull Welder
- Qty (1)-20 KVA Spot Welder
- Certified Welding per AWS D1.1 (Steel, Stainless Steel, Aluminum)
-
Machining
- Qty (1)-3 Axis ProtoTRAK
- Qty (2)-2 Axis ProtoTRAK
- Qty (1)-9"x48" Bridgeport w/Digital Readout & Automatic Feeding
- Qty (2)-CNC Huro
- Qty (1)-HAAS VF-2 Machining Center
-
Support Equipment
- Qty (10)-6'x10' Weld Tables
- Qty (1)-5'x5' Weld Table
- Qty (3) Fork Lifts
-
Cleaning & Painting
- Qty (1)-12'Wx10'D Heated Iron Phosphate Wash Booth
- Qty (1)-9'Hx14'Wx26'L Temperature Controlled, Drive Through Downdraft Paint Booth
